Features

• Supports Bluetooth SPP and GAP
• Power Supply: 5 ~ 12V via Connector or DC Jack


• No external software or host

• Esay Installation and Usage

• Supports the configuration changing of Local Device

• Support the configuration changing of remote device wirelessly

• Type Approval: KC/CE/FCC

• Support the Repeater Functionality

• 100M service coverage(nominal)

• Supports the point to point and the point to multipoint

• RoHS Compliance

• Frequency Range: 2.4 ~ 2.4835 GHz ISM band
• Transmit Power: 100mW (20dBm)
• Receiver Sensitivity: better than - 80dBm
• Antenna: SMA Female
    - Dipole 2dBi / 4dBi
    - Directional Patch 8dBi

• Serial Interface
    - RS-232 Level (optional 3.3V TTL)
    - D_SUB 9-PIN Female
    - Baud Rate: 1.2 ~ 115.2 Kbps
• Operating Environment
    - temperature : -20℃ to 70℃
    - humidity : 85%


• Type Approval: KC/CE/FCC

• Power Supply
    - Operation Voltage: DC 5 ~ 12V
    - Current Consumption: upto 200mA @5V

• RoHS Compliance

• LED Indication
    - Operation/Power: ON or OFF
    - RF Link State: ON or OFF (blinking or off)


• Standard: at least Bluetooth Spec Ver. 2.1
